Description
The Snow & Litter Giant: The Stinger MBHV Series is the ultimate bulk mover. Stepped up from the Series 4, this bucket is engineered for Medium-to-Large Skid Steers, Telehandlers, and Compact Payloaders. Whether you are clearing parking lots of snow, managing feedlot grain, or loading light waste, the MBHV delivers wheel-loader capacity to your compact machine.
Reinforced "Stacked" Construction: Handling 2+ cubic yards of material puts immense stress on the bucket mounts. Stinger answers this with a Stacked Back Plate design—welding a 1/2" plate directly over the 1/4" shell. Combined with a top reinforcement tube, 1/2" side braces, and a rolled insert, this bucket is built to push heavy piles without bowing.
⚙️ Technical Specifications
Shell Material: 1/4" Grade 50 Steel
Back Plate: 1/2" Stacked Reinforcement
Widths: 7 ft (84") to 10 ft (120")
Capacity: 1.5 cu yd to 2.2 cu yd
Wear Protection: 1/2" x 4" Underside Bars
Cutting Edge: 3/4" x 8" (Weld-On or Bolt-On)
Warranty: 1-Year Structural
⚠️ Critical Warning: Machine Width
Oversize Attachment: These buckets range from 84" to 120" wide. They will extend significantly beyond the tires/tracks of standard machines.
Ensure your machine has the torque and traction to push a full 10-foot wide pile.
✅ Machine Compatibility
1. Machine Class:
Large Frame Skid Steers (90HP+), Telehandlers, and Compact Wheel Loaders.
2. Size Recommendation:
7' (84") - 8' (96"): Large Track Loaders (e.g., Bobcat T870, CAT 299).
9' (108") - 10' (120"): Telehandlers & Compact Payloaders (e.g., CAT 906/908, Deere 344).
3. Mount Options:
Standard SSQA. (Other mounts like Euro/Global or JRB may be available upon request).
Additional Specifications
| Mount Interface | Universal Skid Steer |
| Warranty | 1-Year Structural |
| Capacity | 1.5 yd³ |
| Shipping Dimensions (LxWxH) | 40x84x35 |
