Description
The Volume Specialist
The Stinger Series 2 (MB2) is engineered for operators who need to move maximum material per cycle. Unlike standard dirt buckets, the MB2 features an elongated 40.6-inch Deep Bottom. This design drastically increases the struck and heaped capacity, allowing you to carry more loose dirt, mulch, or gravel with every scoop.
Visibility First
High-capacity snow buckets usually have tall backs that block your view. The Stinger MB2 keeps a Standard Back Height (23"), giving you the volume of a larger bucket while maintaining excellent visibility of the cutting edge. Reinforced with 1/2" x 4" wear bars on the underside, it is built to slide along abrasive surfaces all day long.
⚙️ Technical Specifications
Bottom Depth: 40.60 Inches (High Capacity)
Back Height: 23.03 Inches (High Visibility)
Rollback Angle: 68 Degrees
Wear Protection: 1/2" x 4" Underside Wear Bars (4-5 count)
Cutting Edge: 3/4" x 8" (Weld-On or Bolt-On)
Warranty: 1-Year Structural
⚠️ Setup Requirement: Plug & Play
Hydraulics: None required (Mechanical Attachment).
Note: Due to the deep bottom and higher capacity, ensure your machine has adequate tipping load to handle a full bucket of heavy material (wet dirt/gravel).
✅ Machine Compatibility
1. Mount Type:
Universal Quick Attach (SSQA). Fits all standard skid steers and utility tractors.
2. Size Recommendation:
60" - 66": Ideal for Medium Utility Tractors.
72" - 84": Ideal for Medium to Large Frame Skid Steers & Track Loaders.
3. Confirmed Fitment:
- Kubota: SSV75, SVL75-2, SVL95-2, SVL97-2.
- Bobcat: S650, T650, T770, T870.
- John Deere: 320G, 324G, 331G, 333G.
- CAT: 259D, 279D, 289D, 299D.
Additional Specifications
| Mount Interface | Universal Skid Steer |
| Warranty | Universal Skid Steer |
| Capacity | 14.8 cu ft |
| Shipping Dimensions (LxWxH) | 41x60x23 |
| Recommended Machine Class | Medium-Large Frame |
