Schwing Delivery Line Pipes

Schwing delivery line pipes are high-performance conduits designed to transport concrete efficiently from the pump to the placement area. Built to withstand extreme pressure and abrasion, these pipes are a core component of the concrete delivery system.

Key Features

• High-Strength Steel Construction
  Made from ST52, Q235, Q345, 45MN2 steel grades for durability and pressure resistance.

• Abrasion-Resistant Options
  Includes thick-wall designs, hardened finishes (HRC-rated), and twin-wall versions for demanding applications.

• Standard Lengths Available
  Offered in 1m, 2m, 3m, and 6m lengths to suit all site configurations.

• Precision Internal Dimensions
  Ensures smooth concrete flow and perfect fitment with elbows, reducers, and couplings.

• Variety of End Connections
  Options include:

  • Couplings (Clamps): SK, HD, ZX, MF types for quick connection

  • Flanges: Secure, high-pressure bolted systems

  • Weldable Ends: For permanent pipeline installations

• Pump Compatibility
  Purpose-built for integration with Schwing concrete pumps and accessories.

Applications

• Extending concrete delivery lines

• Creating horizontal or vertical pipe runs

• Linking elbows, reducers, and hoses in complex pipeline layouts

Series/Types

• Nominal Diameter (DN): DN50, DN100, DN125, DN150

• Wall Thickness: Standard and heavy-duty options

• Material Grade: ST52, Q235, Q345, 45MN2 with optional hardening

• Connection Types: SK, HD, ZX, MF flanges or clamp connections

• Wear Levels: Standard, hardened, or twin-wall pipes available
